Case Study: Complex commercial aircraft hangar of 93 meters clear span by Everest Industries

Case Study: Complex commercial aircraft hangar of 93 meters clear span

Everest Industries successfully executed a complex designed aircraft hangar building for Indigo without compromising the integrity and safety of the structure

Project Brief
Everest executed a prestigious project of a commercial aircraft hangar with a clear span of 93 m in one of India’s leading metros. Indigo, the end user and consultant had specific limitations of floor area usage strictly imposed by the authorities that were making the design of aircraft hangar impossible by conventional methods – called as ‘fixed base’ design.

Innovation & Solution
The design and engineering team of Everest worked with the consultant and understood the reason for the limitations in space. Once the same was acknowledged as non-negotiable, the design team from Everest revisited the design concept, and successfully performed the design using the ‘pinned base’ philosophy.

In a fixed base design, the vertical columns that support the structure transmit both the imposed loads as well as the moment to the base via their base plates. Since the size of the base plate has a direct bearing on the size of the concrete pedestal where anchor bolts are cast, this directly causes the civil work sizes to increase in the form of a heavier pedestal. In a pinned base design, the moments are absorbed and compensated at  the  joint between the column (vertical member) and rafter (horizontal member). This means that the coupler between the column and rafter (called ‘haunch’) is designed to be much heavier and rigid.

Challenges
The key challenges in a pinned base design include heavier haunches and iterative designs, including the use of kicker elements (plates provided at the haunch) to the higher loads and higher deflections at the center of the rafters. These require an intimate compensation understanding of the interplay between the various forces and the sensitivity of members to each. The engineering team of Everest is very well versed in designing complex structures and it handled the complex design without compromising the integrity and safety of the structure.

Outcome
By using a pinned base, the area of the base plate was reduced by nearly 70 percent and an overall saving of 10 percent was affected in the weight. In addition, the inside-to-inside and outside-to-outside dimensional limitations of the hangar were also maintained.

This is the first case where a pinned base has been used for a large clear-span building of over 90 meters, thus pioneering the implementation of this concept as per customer requirements.
